Packaging
DESCRIPTION:
Flexible steel conduits with inner liner. This product typology offers, besides the characteristics of the round and flat steel conduits, the possibility of having inside a plastic liner in PE-HD, PE-HD mixed MoS2, POM e PTFE.
STANDARDS: UNI 3823 - DIN 17222-17223
APPROVALS:
FEATURES
The data and technical features shown in this page are not binding and can be amended as a consequence of modifications and/or improvements deemed necessary by the manufacturer.The following table shows only the dimensions of some standard products; our production capability can meet any need of the customer. swiss replica watches
|
Item |
? f |
? d |
? D |
|
4,00 A.T. 1,00 |
2,00 |
4,00 |
4,6 |
|
4,00 A.T. 1,25 |
1,50 |
4,00 |
4,60 |
|
4,50 A.T. 1,00 |
2,50 |
4,50 |
5,20 |
|
4,50 A.T. 1,25 |
2,00 |
4,50 |
5,20 |
|
5,00 A.T. 1,40 |
2,10 |
5,00 |
5,70 |
|
7,00 A.T. 1,40 |
4,30 |
7,00 |
8,20 |
|
8,00 A.T. 1,50 |
5,10 |
8,10 |
9,00 |
|
9,00 A.T. 1,70 |
5,50 |
9,00 |
10,00 |
- Pallet 80 x 80cm: mt.5.000 up to al ? 5 / mt.2.500 up to ? 6
- Pallet 80 x 90cm: mt.5.000 up to ? 6 / mt.2.500 up to ? 8 / mt.1.600 up to ? 10
- For conduits of ? 10 or higher variable quantity according to the diameter of the conduit
- Cardboard boxes for conduits until ? 6 mm. in all the kind of coating excluding PVC. Pallet measures cm.110x95x80H - 110x110x75H
