DESCRIPTION:
Round steel flexible conduits. For this kind of product we use steel wire from a diameter of 0,60 to 2,40 mm. for the production of conduits with outer diameter from 2,5 to 14 mm.
KIND OF COVERING: PVC / PE / PA6 / PA11 / others
STANDARDS: UNI 3823 - DIN 17222-17223
APPROVALS:
FEATURES
The data and technical features shown in this page are not binding and can be amended as a consequence of modifications and/or improvements deemed necessary by the manufacturer.The following table shows only the dimensions of some standard products; our production capability can meet any need of the customer.
.
|
Item |
Ø f |
Ø d |
Ø D |
|
4,00 A.T. 1,00 |
2,00 |
4,00 |
4,6 |
|
4,00 A.T. 1,25 |
1,50 |
4,00 |
4,60 |
|
4,50 A.T. 1,00 |
2,50 |
4,50 |
5,20 |
|
4,50 A.T. 1,25 |
2,00 |
4,50 |
5,20 |
|
5,00 A.T. 1,40 |
2,10 |
5,00 |
5,70 |
|
7,00 A.T. 1,40 |
4,30 |
7,00 |
8,20 |
|
8,00 A.T. 1,50 |
5,10 |
8,10 |
9,00 |
|
9,00 A.T. 1,70 |
5,50 |
9,00 |
10,00 |
- Pallet 80 x 80cm: mt.5.000 up to al Ø 5 / mt.2.500 up to Ø 6
- Pallet 80 x 90cm: mt.5.000 up to Ø 6 / mt.2.500 up to Ø 8 / mt.1.600 up to Ø 10
- For conduits of Ø 10 or higher variable quantity according to the diameter of the conduit
- Cardboard boxes for conduits until Ø 6 mm. in all the kind of coating excluding PVC. Pallet measures cm.110x95x80H - 110x110x75H
